Stove and Air Heater Combo (Single Burner)
Fueled by light diesel, this unit combines air heating and cooking functions, providing an integrated cooking and space-heating solution for RVs, yachts, and special-purpose vehicles. It delivers a heating output of 900–1800 W with fuel consumption of 110–192 ml/h. Powered by DC 12 V, it has an average operating current of 0.55–0.85 A. The main unit measures 326 × 359 × 250 mm and weighs 8.8 kg. It supports operation at altitudes of up to 5,000 m and features intelligent high-altitude operation, low noise, and no low-frequency electromagnetic radiation associated with induction cooktops.
Core Advantages
Flameless Cooking
Heat generated by burning light diesel fuel warms the explosion-proof ceramic cooktop, ensuring no open flame in the cooking area. Ideal for compact spaces such as vehicles and boat cabins.
Integrated Cooking and Heating
One unit provides both everyday cooking and warm-air heating, eliminating the need to install separate cooking and heating appliances in limited spaces.
Compact Single-Burner Design
The compact 326 × 359 × 250 mm single-burner design is ideal for small kitchens or worktops in RVs, yachts, and special-purpose vehicles.
Broad Cookware Compatibility
With no reliance on electromagnetic induction, it supports cookware made from iron, aluminum, earthenware, ceramic, and other materials.
Smart High-Altitude Operation
Supports operation at altitudes up to 5,000 m, making it ideal for high-altitude RV travel, modified off-road vehicles, and mobile operations.
Low-Noise Operation
Described as “ultra-quiet” in the original product documentation, it is ideal for mobile living scenarios where restful nights and cabin comfort matter.
Readily Available Fuel
Runs on light diesel fuel with a consumption rate of 110–192 ml/h, allowing convenient refueling alongside diesel-powered vehicles.
No Electromagnetic Radiation Concerns
The heating method does not rely on electromagnetic induction and therefore does not generate the low-frequency electromagnetic waves associated with induction cooktops.
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Voltage | DC 12V |
| Short-Term Maximum Current | 8-10A |
| Average Operating Current | 0.55-0.85A |
| Standby Current | 1mA |
| Heating Power | 900-1800W |
| Fuel Type | Light Diesel/Diesel |
| Fuel Consumption | 110-192ml/h |
| Warm Air Output | 67m³/h max |
| Operating Ambient Temperature | -25°C to +35°C |
| Operating Altitude | ≤5000m |
| Main Unit Weight | 8.8kg |
| Product Shipping Weight | 12kg |
| Dimensions | 326×359×250mm |
| Cooktop Vent Area | ≥40cm² |
| Compatible Cookware | Iron, aluminum, earthenware, ceramic, etc. |
Product Images and Application Showcase
Applications
Compact RV Kitchens
The single-burner design minimizes countertop space while supporting everyday cooking tasks such as boiling, stir-frying, and heating water, and integrates with the vehicle's diesel fuel system.
RV Heating While Parked
When not cooking, the warm-air function provides supplemental heat inside the vehicle. One unit meets both cooking and heating needs, making it ideal for small RVs and camper vans.
Yachts and Boat Cabins
Flameless cooktop cooking is suitable for space-constrained boat cabins. During installation, the fuel system, air intake and exhaust, ventilation, and electrical system must comply with marine regulations.
Special-Purpose and Support Vehicles
Suitable for communications, emergency response, engineering, exploration, and other special-purpose vehicles, providing personnel with basic cooking and warm-air heating capabilities.
High-Altitude Road Trips
The intelligent high-altitude function supports operation at elevations of up to 5,000 m, making it suitable for RV travel across plateaus and mobile operations at high altitudes.
Cold-Weather Camping
Within the product's specified operating temperature range of -25°C to +35°C, it provides hot meals, hot water, and warm-air heating for winter camping.
Recommended Configuration List (Subject to the Order Confirmation)
Frequently Asked Questions
What applications is this product suitable for?
It is mainly designed for mobile spaces such as RVs, yachts, and special-purpose vehicles, meeting both daily cooking and auxiliary heating needs. Before installation, check the countertop dimensions, ventilation, fuel supply, power supply, and air intake and exhaust conditions.
What fuel and power supply does the product use?
It uses light diesel/diesel as fuel and operates at a rated voltage of DC 12V. The short-term maximum current is 8–10A, and the average operating current is 0.55–0.85A.
What are the heat output and fuel consumption?
The heat output is 900–1800W, and fuel consumption is 110–192ml/h. Actual consumption varies depending on the operating level, ambient temperature, altitude, installation conditions, and load.
What types of cookware can be used?
Various types of cookware, including iron, aluminum, earthenware, and ceramic cookware, can be used. Induction-compatible cookware is not required. The cookware should have a flat bottom, be appropriately sized, and not exceed the cooktop's load capacity.
Can it be used in high-altitude areas?
Yes. The original product specifications indicate that it features an intelligent high-altitude function and can operate at altitudes of up to 5,000m. Before use at high altitudes, confirm the fuel supply, air intake and exhaust, and power supply conditions.
How large should the ventilation opening be for installation?
The original technical specifications require a cooktop ventilation opening of at least 40cm². Since the unit burns fuel, the air intake and high-temperature exhaust must be arranged in accordance with the installation specifications. Exhaust gases must not be allowed to enter the vehicle or cabin.
What precautions should be taken during daily use?
Keep the cooktop surface and ventilation openings clean, and regularly inspect the fuel lines, wiring harnesses, air intake and exhaust, and warm-air ducts. If you notice unusual odors, abnormal exhaust smoke, leaks, error codes, or unusual noises, shut down the unit immediately and inspect it.
